CKYZ 型楔块超越离合器

型号： P5F48D0BE2C972
货期：现货

销售价：
会员价： 最低起 更多会员价
市场价：
商品评分： (共0人评论)

数量： -+
我要询价

商品详情

品牌：
所属分类：楔块式单向离合器
商品编号：G5F48D0BE2C92E

<div style="text-align: center;"><font face="黑体" size="6" color="#ff0000">CKYZ型 楔块超越离合器</font></div><div style="text-align: center;">
<img src="http://xinnuode.com/public/images/1f/26/cf/5074813ac7b8010ffea3522db4924b85fd1340b8.jpg?1598607526#h"></div><div style="text-align: center;"><font size="4">CKYZ 型楔块超越离合器（PB型超越离合器）是一种带自润滑轴承的离合器。主要适用于为避免污染而不能加油或处于密封性结构内而不易加油的场合。</font></div><div style="text-align: center;"><br/></div><div><table cellspacing="0" cellpadding="0" width="533" border="0" style="text-align: center;">
<tbody><tr>
<td class="style1" width="270">CKYZ 型楔块超越离合器基本参数和主要尺寸 </td>
<td class="bai_10" width="281">单位：mm</td></tr></tbody></table>
<table cellspacing="0" cellpadding="0" width="533" border="0" style="text-align: center;">
<tbody>
<tr class="tb_1" bgcolor="#ff7f00">
<td class="tb_line4" rowspan="2" width="23">序<br/>号</td>
<td class="tb_line4" rowspan="2" width="115">型号</td>
<td class="tb_line2" height="20" width="44">公称<br/>转矩</td>
<td class="tb_line2" height="20" width="41">极限<br/>转速</td>
<td class="tb_line4" colspan="9">外形尺寸</td></tr>
<tr class="tb_1" bgcolor="#ff7f00">
<td class="tb_line4" bgcolor="#ff7f00">Tn<br/>(N·m)</td>
<td class="tb_line4">n<br/>(r/min)</td>
<td class="tb_line4" width="33">d</td>
<td class="tb_line4" width="35">d1</td>
<td class="tb_line4" width="36">B</td>
<td class="tb_line4" width="34">C</td>
<td class="tb_line4" width="37">F</td>
<td class="tb_line4" width="35">D</td>
<td class="tb_line4" width="33">A</td>
<td class="tb_line4" width="46">b×t</td>
<td class="tb_line4" width="41">b1×t1</td></tr>
<tr class="tb_line" bgcolor="#bdbec0">
<td class="tb_line" height="22">1</td>
<td class="tb_line" bgcolor="#bdbec0" height="22">CKYZ60×70-14</td>
<td class="tb_line" height="22">100</td>
<td class="tb_line" height="22">1800</td>
<td class="tb_line5" height="22">14</td>
<td class="tb_line5" height="22">14</td>
<td class="tb_line5" height="22">60</td>
<td class="tb_line5" height="22">32</td>
<td class="tb_line5" height="22">25</td>
<td class="tb_line5" height="22">32</td>
<td class="tb_line5" height="22">70</td>
<td class="tb_line5" bgcolor="#bdbec0" height="22">5×2.3</td>
<td class="tb_2" bgcolor="#bdbec0" height="22">5×3.0</td></tr>
<tr class="tb_line">
<td class="tb_line" height="22">2</td>
<td class="tb_line" height="22">CKYZ66×75-18</td>
<td class="tb_line" height="22">120</td>
<td class="tb_line" height="22">1500</td>
<td class="tb_line5" height="22">18</td>
<td class="tb_line5" height="22">18</td>
<td class="tb_line5" height="22">66</td>
<td class="tb_line5" height="22">34</td>
<td class="tb_line5" height="22">29</td>
<td class="tb_line5" height="22">35</td>
<td class="tb_line5" height="22">75</td>
<td class="tb_line5" height="22">5×3.0</td>
<td class="tb_2" height="22">5×3.0</td></tr>
<tr class="tb_line" bgcolor="#bdbec0">
<td class="tb_line" height="22">3</td>
<td class="tb_line" bgcolor="#bdbec0" height="22">CKYZ73×82-20</td>
<td class="tb_line" height="22">200</td>
<td class="tb_line" height="22">1200</td>
<td class="tb_line5" height="22">20</td>
<td class="tb_line5" height="22">20</td>
<td class="tb_line5" height="22">73</td>
<td class="tb_line5" height="22">38</td>
<td class="tb_line5" height="22">33</td>
<td class="tb_line5" height="22">38</td>
<td class="tb_line5" height="22">82</td>
<td class="tb_line5" bgcolor="#bdbec0" height="22">5×2.0</td>
<td class="tb_2" bgcolor="#bdbec0" height="22">5×3.0</td></tr>
<tr class="tb_line">
<td class="tb_line" height="22">4</td>
<td class="tb_line" height="22">CKYZ75×82-20</td>
<td class="tb_line" height="22">250</td>
<td class="tb_line" height="22">1300</td>
<td class="tb_line5" height="22">20</td>
<td class="tb_line5" height="22">20</td>
<td class="tb_line5" height="22">75</td>
<td class="tb_line5" height="22">35</td>
<td class="tb_line5" height="22">35</td>
<td class="tb_line5" height="22">38</td>
<td class="tb_line5" height="22">82</td>
<td class="tb_line5" height="22">5×2.0</td>
<td class="tb_2" height="22">5×2.0</td></tr>
<tr class="tb_line" bgcolor="#bdbec0">
<td class="tb_line" bgcolor="#bdbec0" height="22">5</td>
<td class="tb_line" bgcolor="#bdbec0" height="22">CKYZ80×82-20</td>
<td class="tb_line" bgcolor="#bdbec0" height="22">350</td>
<td class="tb_line" bgcolor="#bdbec0" height="22">1200</td>
<td class="tb_line5" bgcolor="#bdbec0" height="22">20</td>
<td class="tb_line5" bgcolor="#bdbec0" height="22">20</td>
<td class="tb_line5" bgcolor="#bdbec0" height="22">80</td>
<td class="tb_line5" bgcolor="#bdbec0" height="22">35</td>
<td class="tb_line5" bgcolor="#bdbec0" height="22">35</td>
<td class="tb_line5" bgcolor="#bdbec0" height="22">38</td>
<td class="tb_line5" bgcolor="#bdbec0" height="22">82</td>
<td class="tb_line5" height="22">5×2.0</td>
<td class="tb_2" bgcolor="#bdbec0" height="22">5×2.0</td></tr>
<tr class="tb_line">
<td class="tb_line" height="22">6</td>
<td class="tb_line" height="22">CKYZ83×85-25</td>
<td class="tb_line" height="22">350</td>
<td class="tb_line" height="22">1000</td>
<td class="tb_line5" height="22">25</td>
<td class="tb_line5" height="22">25</td>
<td class="tb_line5" height="22">83</td>
<td class="tb_line5" height="22">45</td>
<td class="tb_line5" height="22">33</td>
<td class="tb_line5" height="22">40</td>
<td class="tb_line5" height="22">85</td>
<td class="tb_line5" height="22">7×3.0</td>
<td class="tb_2" height="22">7×4.0</td></tr>
<tr class="tb_line" bgcolor="#bdbec0">
<td class="tb_line" bgcolor="#bdbec0" height="22">7</td>
<td class="tb_line" bgcolor="#bdbec0" height="22">CKYZ95×92-30</td>
<td class="tb_line" bgcolor="#bdbec0" height="22">500</td>
<td class="tb_line" bgcolor="#bdbec0" height="22">1000</td>
<td class="tb_line5" bgcolor="#bdbec0" height="22">30</td>
<td class="tb_line5" bgcolor="#bdbec0" height="22">30</td>
<td class="tb_line5" bgcolor="#bdbec0" height="22">95</td>
<td class="tb_line5" bgcolor="#bdbec0" height="22">60</td>
<td class="tb_line5" bgcolor="#bdbec0" height="22">37</td>
<td class="tb_line5" bgcolor="#bdbec0" height="22">41</td>
<td class="tb_line5" bgcolor="#bdbec0" height="22">92</td>
<td class="tb_line5" height="22">8×3.5</td>
<td class="tb_2" bgcolor="#bdbec0" height="22">8×3.3</td></tr>
<tr class="tb_line">
<td class="tb_line" height="22">8</td>
<td class="tb_line" height="22">CKYZ113×100-40</td>
<td class="tb_line" height="22">900</td>
<td class="tb_line" height="22">800</td>
<td class="tb_line5" height="22">40</td>
<td class="tb_line5" height="22">40</td>
<td class="tb_line5" height="22">113</td>
<td class="tb_line5" height="22">65</td>
<td class="tb_line5" height="22">37</td>
<td class="tb_line5" height="22">50</td>
<td class="tb_line5" height="22">100</td>
<td class="tb_line5" height="22">10×3.3</td>
<td class="tb_2" height="22">10×3.3</td></tr>
<tr class="tb_line" bgcolor="#bdbec0">
<td class="tb_line" height="22">9</td>
<td class="tb_line" bgcolor="#bdbec0" height="22">CKYZ133×120-45</td>
<td class="tb_line" height="22">1250</td>
<td class="tb_line" height="22">700</td>
<td class="tb_line5" height="22">45</td>
<td class="tb_line5" height="22">45</td>
<td class="tb_line5" height="22">133</td>
<td class="tb_line5" height="22">75</td>
<td class="tb_line5" height="22">50</td>
<td class="tb_line5" height="22">54</td>
<td class="tb_line5" height="22">120</td>
<td class="tb_line5" bgcolor="#bdbec0" height="22">12×3.5</td>
<td class="tb_2" bgcolor="#bdbec0" height="22">12×4.5</td></tr>
<tr class="tb_line" bgcolor="#ffffff">
<td colspan="13">
<p class="hei1_9"><strong>◆</strong> CKYZ 系列相当于 TSUBAKI 公司 PB 系列
。<br/><strong>◆</strong>订货时请注明向M方向视之内环旋转方向。</p>
</td></tr></tbody></table></div>
